| Characteristics
| |
Length
|
24.9 ft | |
Height |
8.4 ft | |
Wing span |
31.8 ft
|
|
Wing area |
145 sq ft
| |
Seats/arrangement | 2-Tandem | |
Engine type
|
Rotax
912 F |
|
Engine power @ 5.800 RPM |
80 Hp
|
|
Propeller
|
2-blade, fixed
pitch |
| Useful Load |
550 lbs |
| Standard empty
weight |
880 lbs |
| Max. gross weight
(MTOW) |
1,430 lbs |
| Fuel capacity |
18 gals
|
| Performance
(@MTOW, sea level) |
| Take off distance (ground
roll) |
780 ft |
| Take off distance over 50
ft obst. |
1,345 ft |
| Landing distance (ground
roll) |
443 ft |
| Landing distance over 50 ft
obst. |
705 ft |
| Rate of climb, sea level
|
700 fpm |
| Fuel consumption (@ 75%
power, s.l.) |
4,3 gal/hr |
| Service ceiling |
13,500 ft |
| Cruise speed (@ 75% power,
s.l.) |
90 kts |
| Maximum Speed
|
104 kts |
| Never exceed speed
(VNE) |
132 kts |
| Stall Speed (full
flaps) |
40 kts |
| Endurance: (@ 75 % power,
no res.) |
4h 15' |
| Max range: (@ 75% power, no
res.) |
380 nm
|
|
