| Characteristics
| |
Length
|
24.9 ft | |
Height |
8.4 ft | |
Wing span |
31.5 ft
|
|
Wing area |
145 sq ft
| |
Seats/arrangement | 2-Tandem | |
Engine type
|
Rotax
912 ULS |
|
Engine power @ 5.800 RPM |
98 Hp
|
|
Propeller
|
3-blade, ground adjustable
pitch |
| Max. gross weight
(MTOW) |
1,320 lbs |
| Standard empty weight |
840 lbs |
| Useful
Load |
480 lbs |
| Max Fuel capacity |
26.4 gals
|
| Performance
(@MTOW, sea level) |
| Take off distance (ground
roll) |
470 ft |
| Take off distance over 50
ft obst. |
890 ft |
| Landing distance (ground
roll) |
360 ft |
| Landing distance over 50 ft
obst. |
660 ft |
| Rate of climb, sea level
|
1,100 fpm |
| Fuel consumption (@ 75%
power, s.l.) |
4,9 gal/hr |
| Service ceiling |
13,500 ft |
| Cruise speed (@ 75% power,
s.l.) |
95 kts |
| Maximum
Speed |
110 kts |
| Never exceed speed
(VNE) |
132 kts |
| Stall Speed (30° flaps
DN) |
38 kts |
| Endurance: (@ 75 % power,
no res.) |
5h 20' |
| Max range: (@ 75% power, no
res.) |
501 nm
|
|
